Belt replaces Cox V25, Cub Cadet 754-0644 or 954-0644, John Deere M188184, Kingcat V25, Scag 482171 OR Victa VC-28001

Belt Replaces:

Cox   V25
Cub Cadet   754-0644 or 954-0644
John Deere   M188184
Kingcat   V25
Scag   482171
Victa   VC-28001

___________________________________________________________

Fits:

Cox
New Generation
40" cut   1998 - 2002    Side discharge 13hp, 14hp, 14.5hp, 16.5hp, 16hp and 18hp   5302G, 5303L, 5398A, CR5327, CR5326 and CR5318 as the cutter deck belt
Stockman New Era
40" cut   9005J and A10406C as the cutter deck belt

Cub Cadet
42" cut   SELECTED models only, as the cutter deck belt
* Does NOT fit all.  Check the manufacturer's belt# *

John Deere
108, 111, 112L, 116, STX30 and STX38 as the transmission drive belt

Kingcat
32" cut   side discharge 13hp manual and 16hp electric clutch models ONLY   KR6901, KR6902, KR6903, KR6905, KR6906, KR6907 and KS6904 as the PTO to cutter deck belt
32" cut   7300J, KR7303, KR7306,KR7307, KR7308 and KR7311 as the cutter drive belt
32" cut   7301I, KR7315, KR7316, KR7317, KR7318, KR7319, KR7320, KR7321, KR7322, KR7323 and KR7324 as the cutter drive belt

Scag
52" cut   Turf Tiger as the pump drive belt
61" cut   Turf Tiger as the pump drive belt

Victa
32" Cut   13hp VR032-13HC as the cutter deck belt

___________________________________________________________

Belt Details:

Width: (inches) 1/2" (mm): 12.7mm
Inside circumference (inches) 58" (mm): 1473mm
Outside circumference (inches) 60" (mm): 1524mm
(Non-genuine)
Made with KEVLAR™

Please check your manual for the correct belt number as there could be multiple applications.
Manufacturers have uploaded manuals online.

All parts need to be fitted by a licensed Technician

• High quality aftermarket replacement belt
• Certified in manufacture ISO/TS16949:2016 and ISO 14001 OHSAS 18001
• PIX belts meet the 'essential' Health and Safety norms for its entire range of fire-resistant, anti-static belts
